Select Installation Tee or SS weld-on to complete your Order
Features
- Inexpensive and accurate
- Each fitting is individually calibrated and marked with K factor(ml/pulse)
- Ceramic ball bearing for superior low flow performance
- High amplitude pulse output signal can travel even 100-meter distance without the need of transmitter
- Insertion type sensor also available with solvent cementable adaptors for PVC tees
- Fitting automatically set probe at correct depth and orientation
- SS Tri clover sensor for Food grade & pharma application
| LINE SIZE | FLOW RANGE | |
|---|---|---|
| M³/hr | ||
| MIN | MAX | |
| 40 NB | 0.5 | 19 |
| 50 NB | 3.5 | 35 |
| 65 NB | 5 | 50 |
| 80 NB | 9 | 90 |
| 100 NB | 14 | 140 |
| 125 NB | 22 | 220 |
| 150 NB | 30 | 300 |
| 200 NB | 50 | 500 |
| Line Size | 80 NB, 100 NB |
|---|
